robe pointe

A compact and versatile moving head wash beam ligh It features a 7 x 40W RGBW LED engine, delivering intense colors and smooth dimming. The fixture offers ultra-fast movement, seamless color transitions, and multiple control options, making it ideal for dynamic lighting setups in concerts, theaters, and live events.



The spectacular zoom range of 3.8° to 60° uses an eminent custom-designed optical system, now equipped with Robe's innovative lens coating technology which brings benefits such as bright and clear lenses, no scratches or marks, higher light output and longer intervals between cleaning. The unique LEDBeam 150 FW offers Fresnel-Wash type of light output for even smooth edges and better color homogenization.

Attractive colorful chases and smooth transitions are powered by a cluster of high power multichip 40W RGBW LEDs.A highly optimized motorised control produces speedy pan and tilt movement. Besides intense strobing capabilities, both LEDBeam 150 and LEDBeam 150 FW also offer gentle 18-bit dimming, including Tungsten lamp effects.

Source

Light source type: 7x 40W RGBW multichips

LED life expectancy: min. 50.000 hours

Typical lumen maintenance: L70/B50 @ 50.000 hours

Optical system

Robe’s proprietary optical design

High - efficiency zoom optical system, ratio: 15,5:1

Zoom range: 3,8° - 60°

Fixture total lumen output:

  • 3.550 lm (integrating sphere)

  • 2.842 lm (goniophotometer)

Illuminance: 12.200lx @ 5 m

RLCT™ Innovative lens coating technology

Dynamic Effects and Features

Colour mixing mode RGBW or CMY

Variable CTO: 2.700K - 8.000K

DataSwatch™ filters: pre-programmed 66 colours and tones including most used whites 2.700K, 3.200K, 4.200K, 5.600K and 8.000K

Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4.200K (red shift and thermal delay)

Motorized zoom

Pre-programmed random strobe & pulse effects

High resolution electronic dimming: 0 - 100%

Control and programming

Setting & Addressing: two-row LCD display & 4 control buttons, stand-alone operation with 3 editable programs (each up to 40 steps)

Protocols: USITT DMX-512, RDM

Wireless CRMX™ technology from Lumen Radio - on request

DMX Protocol modes: 2

Control channels: 22, 16

Pan/Tilt resolution: 8 or 16 bit

RGBW/CMY: 8 or 16 bit

Zoom: 8 or 16 bit

Dimmer: 8 or 16 bit (internal 18 bit)

Movement

Pan movement: 450°

Tilt movement: 228°

Movement control: Standard and Speed

Controllable speed of Pan/Tilt movement

Automatic Pan/Tilt position correction

Thermal specification

Maximum ambient temperature: 45°C (113°F)

Maximum surface temperature: 80°C (176°F)

Minimum operating temperature: -5°C (23°F)

Noise Levels

Sound pressure level:

  • 18 dB(A) at 1 m (quiet mode)

  • 34 dB(A) at 1 m (auto mode)

Sound power level:

  • 26 dB(A) (quiet mode)

  • 42 dB(A) (auto mode)

Electrical specification and connections

Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: Max. 220 W

Power in/out connector: Neutrik powerCON in/out

DMX and RDM data in/out: Locking 5-pin XLR

Mechanical specification

Height: 337 mm (13.3")

Width: 244 mm (9.6")

Depth: 149 mm (5.9")

Weight: 5.7 kg (12.6 lbs)

Ingress protection rating: IP20

Rigging

Mounting points: 1 pair of ¼-turn locks

1x Omega adaptor with ¼-turn quick locks

Universal operating position

Safety cable attachment point
